Generic 4 Door 4 Readers Professional TCP/IP Network Access Control Controller Board

Specifications of the Access Control Board: A Communication:TCP IP B Software support data base:SQL C Description: Control 4 door,entry&Exit by card&keypad or exit by hit button D Power Supply 12VDC; 4-7A E Power Consumption of Circuit Board: Less than 100mA F Input Format of Reader: Wiegand 26/34 bit (All card reader with compatible protocol, such as Motorola , ID, EM ,IC one etc) G Quantity of Readers: 4 H Door Controlled: 4 I Door opening time extending setting: 1-600 Seconds(adjustable) J Max q ' ty of controller: Unlimited Technical details : I Operation Temperature: -40°-70° II Operation Humidity: 10-90 % RH ,No Condensation III Q ' ty of users: 20,000 Users IV Q ' ty of Event Buffers(offline): 100,000 Event Buffers V Power interruption: protection measure High Speed Memory, Records never lose VI Max Distance: from Reader to Controller 100M (suggestion distance 80m) VII Max Distance: between Controllers Depand on network range VIII Collocations: PCB board, case, power, power line, serial port communication line, software, manual, certificate, key(2pcs), carton VX Alarm functions: Alarm for long time door open, ilegal break in, intimidate X Fire and alarm linkage: If no connection with the expansion board,,only has software interface alarm, and drive the computer speaker. If connected with expansion board, is able to alarm by hardware, if connected with strengthened expansion board, then is able to Security alarm Software: 1. Support ACCESS & SQL database. 2. Offline Operation. 3. Real-time Supervision. 4. Photo Display. 5. Mass Storage. 6. Flexible user privilege setup. 7. Remote Unlocking. 8. Multi-user supervision. 9. Simply checking and query 10. Revisable and printable report form. 11. Report can be exported to EXCEL file. 12. Card+password unlocking. 13. Alarm door left open (reauires door sensors) 14. Alarm for invalid card swiping. 15. First card unlocking. 16. Alarm for illegal break in. 17. Unlocking at specified time.
