GARTT HobbyWing QuicRun WP 1060 Brushed 1:10 60A Electronic Speed Controller ESC Switch Mode BEC New Version

Features
- This ESC is specially designed for new beginners and intermediate modelers; it not only carries forward the outstanding quality of HOBBYWING products but simplifies the operation.
- The waterproof and dust-proof design allows the QUICRUN WP-1060 Brushed to be used in all weather conditions without any issue of damage caused to the ESC from water or dust.
- Reliable hardware combined with advanced software technology allows the QUICRUN WP 1060 Brushed to not only provide high power output but also overload protection of the ESC circuit.
- This ESC features auto throttle calibration and parameter setting via jump caps is easy-to-use, especially applicable to new beginners.
- This ESC is designed for 1/10th scale touring cars, buggies, short-course trucks, monster trucks, trucks, crawlers and tanks.

Specifications
Scale 1/10th
Brushed/Brushless Brushed
Waterproof WP
Specifications Cont./Peak Current 60A/360A
Input 2-3S LiPo/6-9 Cells NiMH
BEC Output Switch Mode:6V/3A
Input Wires Red-16AWG-100mm*1/Black-16AWG-100mm*1
Output Wires B lue-16AWG-100mm*1/Yellow-16AWG-100mm*1
Input Connectors Big-sized TAMIYA Connector
Output Connecotors 4.0 Bullet Connectors (Female)
Program Port Jumper Cap
Size 36.5x32.0x18.0mm
Weight 39g
Applications
Motors Brushed Motors
Vehicles 1/10th Touring Cars/Buggies/Trucks/Rock Crawlers
KV Rating/T Count 2S LiPo: T‰¥12T 3S LiPo: T‰¥18T (540/550 Size Motors)
(Note: All the wire length above is the original length not the length you see from the outside.)

Package Included
QuicRun WP 1060 Brushed * 1
