FactoryDiscountStore 3040T-DQ 3 Axis Cnc Router Engraving Engraver Machine Carving Cutter Drilling And Milling Cutting Tools (3040T-DQ)

Technical Parameters

Engraving area:390mm x 285mm

Effective working travel:390(X)mm x 285(Y)mm x 55(Z)mm

Shape dimension:610x485x395mm

Max.workpiece dimension:‰¤70mm

Z-Axis stroke:55mm,Engraving depth depends on the length of the tool edge

Frame materials:aluminum alloy 6063 and 6061(The unique and dedicated mold extrusion profiles,Let counterfeiters dwarfs)

Type of screw:Ball screw,Pitch 4mm

Rail type:Chromeplate shaft+Liner Bearing,(Surface hardening 61 HRC)

Driving units X axis:1204 trapezoidal screws

Driving units Y axis:1204 trapezoidal screws

Driving units Z axis:1204 trapezoidal screws

Sliding units X axis:Dia.16mm chrome plate shafts

Sliding units Y axis:Dia.20mm chrome plate shafts

Sliding units Z axis:Dia.12mm chrome plate shafts

Stepping motor type:2-phase hydird stepping motor,1.8A/PHASE,60N.8 segments drive

Principal axis collet:ER11,1/8'(3.175mm) Collet

Repeat accuracy:0.05mm

Spindle precision:radial beat acuities 0.03 mm

Control unit:triaxial one-piece drive + ring variable power + PWM speed

Carving Instructions:G code/.nc/.ncc/.tab/.txt

Communication interface:through parallel connection with computer

Software compatability:Mach3/Emc2/Kcam(Type3,Wentai,ArtCAM,Coppercam)

Maximum speed:0-4000mm/min(Engraving speed:300-3000mm/min)

Control unit:Toroidal transformer + PWM power supply module + TB6560 3axis drive board

Computer connection:on board palrallel port

Command code:G code

Acceptable software:Mach3,EMC2

Protection:Emergency stop button

Feature

1.Mach 3 software is simple and intellgent

2.Can control the engraving more precise

3.Large 3D engraving in soft wood,MDF board,native wood,PVC,Acrylic.

4.with automatic tool setting function of Z axis.
