Eteyo Professional Solder Paste Glue Dropper Liquid Auto Dispenser Controller

How to use

Please refer to the following product user manual

http://www.jinlantrade.com/ebay/liquiddispenser/img.pdf

Introduction:

Automatic Liquid Dispenser with time control,to push the liquid pneumatically,controlled by timer,to be sure the same dispensing drops and dispensing cycle time,regulated the air pressure with suitable tip at your equipments of the different liquids as glues,greases,solder pastes.Applied for 10 types of steel tips and 5 types of plastic tips for various customer's needs.

Technical Parameters:

1.Timer: Programmale: 0.01-1S,0.1-10S,0.2-20S,0.3-30S

2.Cycle Initiation:Maintained or Momentary

3.Repeat tolerance: ±0.5%

4.Size:235x225x63 mm³

5.Internal voltage: 24V DC

6.Minimum deposit: 0.01ml

7.Air input: 2.5 to 7 bar(35 to 100psi)

8.Air output: 0.1 to 5.5 bar(1 to 78psi)

Features:

1.Two controlling modes: manual mode & auto mode.

2.Precise control of dispensing drops and dispensing cycle.

3.Suck-back function ensures no leakage drops.

4.Work great for secure the SMD components position before soldering work.

5.Suitable for many different liquids, such as quick-drying glue, red glue, yellow glue, epoxide-resin glue, silica gel, grease, screw locking glue and soldering flux.

6.System comes with 3 30cc liquid barrels, 6 steel needle/tips and 6 plastic tips. This unit need to be connected to air compressor.
