Eleduino Banana Pro Dual Core Raspberry Pi-like Source Single-board Computer with Wifi/ Gigabit Ethernet /Sate Port Standard Start Kit

Banana Pro has more enhanced features. an excellent compatibility with multiply software supports. Basically all mainstream Linux-based operating system can run on Banana ProTM, with the version of Lubuntu, Android, Debian, Bananian, Berryboot, OpenSuse, Scratch, Fedora, Gentoo, Open MediaVault, OpenWRT,BSD system .
Hardware Specification:
Soc:Allwinner A20(sun 7i): CPU:ARM CortexTM-A7 Dual-Core1GHz (ARM v7 instruction set)
GPU:Mali400MP2 Complies with OpenGL ES 2.0/1.1 (hardware acceleration support)
SDRAM:1GB DDR3 (shared with GPU)
Power:5V @ 2A via MicroUSB (DC in Only) and/or MicroUSB (OTG)
PMU:AXP209
Features:Low-level perpherials
40 Pins Header:28-GPIO, some of which can be used for specific functions including UART, I2C, SPI, PWM, CAN, I2S, SPDIF, LRADC, ADC, LINE-IN,FM-IN,HP-IN.
On board Network:10/100/1000Mbps ethernet (Realtek RTL8211E/D)
Wifi Module:WiFi b/g/n
Bluetooth:Optional
On board Storage:MicroSD (TF) cardïŒSATA 2.0
Display:Supports multi-channel HD display:
HDMI 1.4 (Type A - full)
LVDS/RGB/CPU display interface (DSI) for raw LCD panels
Composite video (PAL and NTSC) (via 3.5 mm TRRS jack shared with audio out)
11 HDMI resolutions from 640-480 to 1920-1080 plus various PAL and NTSC standards
Video:HD H.264 2160p video decoding
Mutil-format FHD video decoding, including Mpeg1/2, Mpeg4, H.263, H.264, etc H.264 high profile 1080p@30fps or 720p@60fps encoding Audio outputs:HDMI,analog audio Camera:Parallel 8-bit camera interface
Audio input:On board micphone
USB:2 USB 2.0 host, 1 USB 2.0 OTG (all direct from A20 chip)
Package list :
banana pro main board*1
User guide *1
Eleduino case*1
Asus 5v 2A adapter*1

  • TitleEleduino Banana Pro Dual Core Raspberry Pi-like Source Single-board Computer with Wifi/ Gigabit Ethernet /Sate Port Standard Start Kit
  • Brandeleduino
  • ManufacturerEleduino
  • BindingPersonal Computers
  • ProductGroupPersonal Computer
  • UPCs710824098038
  • EANs0710824098038
