EPAuto 30/40 AMP Relay Harness Spdt 12V, 5-PIN SPDT Bosch Style - 5 Pack

Contact Capacity:

Normal switching Capacity (res.load):
    - NO 40A 14VDC
    - NC 30A 14VDC
Max. switching current: 40A
Max. switching voltage: 30VDC
Max. switching power: 560W

Characteristic Data:

Initial contact resistance (at 6VDC 1A): 50mΩ Max.
Operate time (at nominal volt.): 10 msec. Max.
Release time (at nominal volt.): 5 msec Max.
Initial insulation resistance: 100MΩ Min. (DC500V)
Initial dielectric strength:
    - Between open contacts: AC500V, 50/60 Hz 1Min.
    - Between coil and contact: AC500V, 50/60 Hz 1Min.
Vibration resistance:
    - Functional: 10 ~ 55Hz at double amplitude of 1.5 mm
    - Destructive: 10 ~ 55Hz at double amplitude of 1.5 mm
Shock resistance:
    - Functional: 20G Min.
    - Destructive: 100G Min.
Endurance (operations):
    - Mechanical (at 7,200 ops./h): 10,000,000
    - Electrical (at 600 ops./h): 100,000
Ambient Temperature: -40°C ~ +125°C (no condensation)
