ELVID StudioVision Dual 7"" Monitor Rackmount



Key Features
Two LED backlit IPS monitors in a 19" rackmount
1280 x 800 resolution
800:1 contrast ratio
178° viewing angle
3G-SDI, HDMI, Composite, and Component inputs and loop outputs
DB-15 tally connector
Software control via Ethernet connection (software included)
Dedicated control buttons and function button per monitor
16:10, 16:9, 4:3, 1.85:1, 2.35:1 aspect ratios
Bare end tally adapter included

Monitoring Features
H/V Delay
Underscan
Center Marker
Safety Marker
Picture-in-Picture
1:1 Pixel-to-Pixel
Zoom (up to 8x)
Check Field
Color Bar
Image Flip
Freeze Input
Adjustable color temperature

Display: 2 x 7" (17.8 cm) LED backlit IPS panels

Aspect Ratios: 16:10, 16:9, 4:3, 1.85:1, 2.35:1

Resolution: 1280 x 800

Contrast Ratio: 800:1

Brightness: 400 cd/m²

Viewing Angle: 178°/178°

Inputs: Per Monitor: , 1x 3G-SDI , 1x HDMI , 1x Composite on BNC , 1x Component on BNC , , For Both Monitors: , 1x Tally on DB-15 connector , 1x RJ-45

Outputs: Per Monitor: , 1x 3G-SDI loop output , 1x HDMI loop output , 1x Composite loop output on BNC , 1x Component loop output on BNC

Input Voltage: 7 - 24 VDC, 1.5 A

Current: 1500 mA

Power Consumption: ? 18 W

Dimensions: 18.9 x 5.3 x 1" (48 x 13.5 x 2.5 cm)

Weight: 6.4 lb (2.9 kg)
