Dayton DC Parallel Shaft Permanent Magnet Gear Motor 3.4 RPM,  1/425hp 12 Volts DC Model 2L005

Technical Specification Item DC Gearmotor Voltage 12VDC Shaft Orientation Parallel Reversible Shaft Output No Nameplate RPM 3.4 Max. Torque 44 in.-lb. Overhung Load 28 lb. Input HP 1/425 Gear Ratio 1176:1 Full Load Amps 0.50 Insulation Class B Enclosure Vented Thermal Protection None Max. Ambient Temp. 40 Degrees C Rotation Reversible Mounting All Position Motor Type Permanent Magnet DC Length Less Shaft 3 Overall Length 4 Bearings Bronze Sleeve on Both Case and Motor Lubrication Grease Filled Gear Material Delrin and Steel Gear Type Spur Gear Case Die Cast Zinc Housing Material Die Cast Zinc Application For Industrial and Agricultural Valve Actuators RPM Range 0 to 15 Compliance & Restrictions Compliance and Restrictions Hazardous material - General This listing is for each. _DELETE_
