DROK Small Digital Voltage Ampere Multimeter 110V 220V AC 80V-300V 100A Volt Current Meter Voltmeter Ammeter Gauge Sense Transformer LED Dual Panel Display Detector with Current Sense Transformer

Parameters:
Accuracy: 1% +/- 2 digits
Measuring Range: AC 80-300V, 0.2-100A (with sensor transformer)
Power Consumption: < 0.2 VA
Measurement speed: about 2 times / sec
Display: 3 LED digital tube
Display Color: voltage in red, current in yellow
Dimensions: 70x42x32mm
Installation Size: 68x38 mm (flush mounting)
current sense hole diameter: 15.5 mm
Working Mode: voltage and current dual display
Wiring: two wires connection

Applications:
The meter can be used in charger, inverter, solar energy, wind turbines, LED lights measurement, distribution box, voltage regulator,education appliances, appliance Repair, flapper, etc.

Note:
1.The meter only suits for pure AC 50-60HZ power supply and CANNOT be used for square wave,inverter output and sine wave circuit measurement of modified sine wave, or the meter will be damaged forever.
2.This meter can directly replace 85L17 Analog current and voltage meter
3.The meter requires no power supply and AC transformers(because the meter includes the ac transformer)

Wiring sequence:
1. Connect current loop
2. Connect the AC power supply
3. Please do not touch any components and circuit,to avoid electric shock

Package Included:
1x Digital Volt Amp Meter 2in1
1x Transformer
