DROK® PWM DC Stepper Motor Speed Controller Pulse Width Modulation Stepless Control Module DC 10-60V 30A 600W Switch Dimmer Governor

Parameters：
Operating voltage: DC 10-60V
Max Current: 30A
Control Power: 600W (MAX)
Static Current: 0.02A (standby)
PWM duty cycle: 5% -99% (stepless)
PWM Frequency: 19khz

Features:
1. Its anti-dust potentiometer can separate from the board and you can use cable to connect potentiometer with the board.
2. Aluminum body prevents it from easily damaged. Red LED indicator will light on when power the module on.
3. Double tube driving allows small heating, high efficiency and more stable performance. It can control motor speed to change from 2% to 100%.
4. With high-frequency capacitance and connecting post for input and output; wide voltage suits for 9-60V and max current could be 20A
5. The module can control your motor to rotate in positive direction or in reverse direction.
6. By screwing the potentiometer, you can turn off power supply output.

Note:
1. The governor must be connected to DC power, you cannot connect the 220V AC power directly.
2. The positive and negative cannot be reversed.
3, Please exchange the motor wiring If the motor is rotating in the wrong direction.
