DROK DC-DC Buck Converter Module 90W Step Down Voltage Regulator Reducer Converter 4.5-60V to 1.2-30V 3A Adjustable Volt Transformer for Battery Golf Cart 48V to 24V

Feature:
Module Properties: non-isolated step-down module (buck)
Rectification: non-synchronous rectification
Input voltage: DC 4.5-60V
Output voltage: DC 1.25-30 adjustable
Output Current: 3A. Can 30V 3A 90W at full load. Please enhance heat dissipation.
Efficiency: Up to 92% (the smaller the pressure, the higher the efficiency)
Switching frequency: 50KHz
Lowest dropout: 2V
Operating Temperature: Industrial (-40°c to +85°c) (output power 20W or less)
Full load temperature rise: 40°c
Load regulation: +/- 0.5%
Voltage regulation: +/- 0.5%
Output ripple: Input 48V, Output 5V, 3A, ripple less than 10mV
Bandwidth: 20M
Dynamic response speed: 5% 200uS
Short circuit protection: current limiting, since the recovery (output voltage lower than 20V)
Output over-voltage protection: None
Input Reverse Polarity Protection: Yes.
Installation: screw (diameter 3 mm), 2 mounting holes, 2 holes spaced 82mm
Shell: All aluminum, casting process, can work in harsh conditions

Some Applications
Buck: 12V 24V 36V 48V battery, Input can withstand up to 60V, output stable 3.3V 5V 9V 12V 24V and so on.
POE remote power supply. switches, routers, 48V long-distance transmission powered

Package Include:
1x DC/DC Buck Converter
