DROK® AC 80-300V/50A 110V 220V Digital LED Amp Volt Meter Ammeter Voltmeter Gauge with Current Sense Transformer

Features:
Working Mode: Voltage and current dual display, two wires connection
Measuring Range: AC 80-300V, 0-50A (built-in sensor transformer)
Display:  3 LED digital tube
Display Color: Voltage Red, Current Green
Accuracy: 1% +/- 2 digits
Power Consumption: < 0.2 VA
Measurement speed: about 2 times / sec
Dimensions: 70x42x40mm
Installation Size: 68x38 mm (flush mounting)
current sense hole diameter: 7mm
Can directly replace 85L17 Analog current and voltage meter
Uses:Charger, inverter, solar energy, wind turbines, LED lights measurement and etc.

Wiring sequence:
1, Connect current loop
2, Connect the AC power supply
3, Please do not touch any components and circuit,to avoid electric shock

Package Included:
1x Digital DC Voltmeter Ammeter 2in1
