Ctronics CCTV Tester Full Function 7" Touch Screen 1080P HDMI IP Camera CCTV Tester/POE Test/WIFI Digital Multi-meter/Optical Power Meter/Visual Fault Locator/TDR/SDI CTIPC-8600MOVTS Full Function

Specifications:
Display: 7 inch Capacitive touch screen , resolution 800(RGB)x 600
Network port:10/100M auto adjust,RJ45/wifi
Video level test:1 channel BNC Input & 1 channel Output , NTSC/PAL (Auto adapt)
Video level meter:PEAK video signal level, SYNC signal level, COLOR BURST chroma level measurement
Zoom Image:Analog camera and IP camera image zoom /move
Snapshots,Video record,Record playback:Image Screenshots, record ,save ,view and record play back
HDMI output:1 channel HDMI output,support 1920*1080P
12V/2Apower output/5V power output:5V 2A power output,as a mobile phone Power bank/PoE power output:48V PoE power
Audio test:1 channel audio signal input, test whether sound normal, 1 channel audio signal, to connect headphone
PTZ control:Support RS232/RS485 control, Baud 600-115200bps, Compatible with more than 30 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, Yaan, etc
Video Signal Generator:Output one channel PAL/NTSC color bar video signal for testing monitor or video cable.(red, green ,blue, white and black color)
Network color bar generator:Local side PC can login the tester, send the signal by network ,test network connection communication whether normal
UTP Cable tester:Test UTP cable connection status and display in the screen. Read the number on the screen
Data monitor:Captures and analyzes the command data from controlling device,also can send hexadecimal
Network test:IP address scan, link scan, Ping test, Quickly search the connection IP camera and other device's IP address
Cable scan:Search the cable by the audio signal
PoE test:Measurement POE switch or PSE power supply voltage and cable connection status
Digital Multi-meter:AC/DC,Voltage,AC/DC,current,Resistance,Capacitance,Data hold,Relative measurement,Continuity testing . Testing speed: 3 times/ seconds,Data range -6600~+6600.
Visual fault:Test fiber's bending and breakage

  • BindingElectronics
  • EAN6044825934625
  • LabelCtronics
  • ManufacturerCtronics
  • ModelCTIPC-8600F
  • MPNCTIPC-8600F
  • PackageQuantity1
  • PartNumberCTIPC-8600F
  • ProductGroupPhotography
  • ProductTypeNameSURVEILANCE_SYSTEMS
  • PublisherCtronics
  • StudioCtronics
  • TitleCtronics CCTV Tester Full Function 7" Touch Screen 1080P HDMI IP Camera CCTV Tester/POE Test/WIFI Digital Multi-meter/Optical Power Meter/Visual Fault Locator/TDR/SDI CTIPC-8600MOVTS Full Function
