Constructan(TM)Compatible with MPEG-2/MPEG-4 H.264 TV Set Top Box HD DVB-T2 Digital High Definition Video Broadcasting Terrestrial Receiver


Features:
Hardware Specification:
CPU: MSTAR-MSD7T01(128 pin) MIPS 34Kf@600MHz.
Memory: 32X16Mbit DDR2 Frequency1066.
Flash: 32M bytes.
Demodulator Type: MSB1236C Chip Set
TUNER: Rafael R836.
Decoder:
Video Decoder: Compliant with: MPEG-4 part10/MPEG-2 ISO/IEC 13818.
MPEG-4 Simple/Main/Advanced Profile@LEVEL3(10Mbps).
MPEG-2 Main Profile# Main Level(15Mbps).
H.264 MP#L3(10Mbps).H.264 HP L4.1(25Mbps). AAC-LC, WMA
E-AC-3 (Dolby Digital Plus) decoding HE-AAC 5.1 multi-channel decoding.
Media Codec: avi, mpg, dat, vob, div, mov, mkv, jpeg, etc.
Audio Codec: WMA,MP3,AAC (wma,mp3,m4a).
Photo Codec: JPEG, BMP, PNG.
Demodulation:
Terrisal Receiver Standard: DVB-T2/T(EN_302755 V1.3.1/EN 300744).
Input RF Frequency: 48~866MHZ.
Bandwidth: 6MHz,7MHz,8MHz.
Constellation: QPSK 16-QAM 64-QAM and 256-QAM.
FEC: 1/2, 3/5,2/3, 3/4,4/5,5/6.
Guard Interval: 1 / 128 1 / 32 1 / 16 19 / 256 1 / 8 19 / 128 1 / 4.
FFT Mode: 2K/ 8K / 32K.
Support: Support Single and multiple PLPS.
Input level: -83 - -5dBm.
License: Optional DTS, Dolby Digital, Dolby Digital Plus, RM/RMVB, Divx License.

Specifications:
Color: Black
Front Panel: One embedded USB 2.0 host (USB Recording PVR) and 4-Digit LED display on front panel. Red LED Standby and Green LED Lock; Panel Keys (POWER, CH+ ,CH-, etc)
Rear Panel: 1 * ANT-IN connector (IEC-162-2 Female); 1 * ANT-OUT connector (IEC-162-2 Male); 1 * HDMI (Compatible with HDMI V1.3/V1.4), 1 * RCA CVBS AL AR Connector; 1 * Ypbpr RCA; 1 * Coaxial.
Power Supply: AC 90~240V 50Hz/60Hz
Item size: 16.8 * 11.0 * 3.5cm / 6.61 * 4.73 * 1.38in
Item weight: 335g / 11.84oz

Package list:
1 * Terrestrial Receiver Set Top Box (Attached EU plug)
1 * IR remote control
1 * RCA Cable
1 * English User Manual
