Chafon Mini USB Rfid 125khz ID Em Proximity Card Reader Support Windows XP Win7/8 Linux Android Operate System for Door Access Control +2 Pcs Em Card(White)
Chafon Mini USB 125khz EM card reader is a high performance, lower price reader.reader distance up to 10cm, widely used for RFID Radio Frequency Identification system and project, such as Automated parking management system, Personal identification, Access controller, Production Access control, etc.
Attention
Output format:10 digit decimal(We default to send);another Output format:8 digit hexadecimal(If require,Confirm with me in advance).
Specifications
Dimension: 74X19X6mm
Colour: White
Support: Em4100,TK4100,SMC4001 and compatible card
Frequency :125KHz
Reader time:0.5s
Baud Rate: 9600
Power Supply : 5V DC
Consumed Current: 70mA
Operating Distance: 0~10cm
Interface : USB
Status Indication:1pc LED
Service Temperature: -10„ƒ ~ +70„ƒ
Store Temperature: -20„ƒ ~ +80„ƒ
Instructions for use:
1. Connet with computer through USB interface directly
2. Open Notepad or a word document.
3. The mouse in Notepad or WORD document clicking.
4. Put card on the top of reader.
5. Notepad or word documents will output of the ID card number.
6. When Reading one card, LED lights turns red into the blue.
Package include:
1X Mini USB RFID Reader
2X EM Card.
Warm tips
If there is any problems in the using process,please feel free to contact us.
Our technical support will help you to solve these problems.
Please note:
Not support IOS system
Don't Support HID Card and HID Chip
Doesn't work with badging system
