CNC 4 Axis TB6560 USB Interface Breakout Board Kit with Stepper Motor Driver Power Supply Stepper Motor 1.2N.m 2.8A

A. CNC USB Interface Breakout Board:
1: The maximum matching 5-axis stepper motor driver
2: The two-stage signal processing, signal transmission smooth, powerful anti-jamming
3:5 input interface to define the emergency stop, limit, points in the knife, etc.
4: relay output control interface, can be accessed by the spindle motor or the air pump, water pump, etc
5: five-axis job LED display, visual display products, working condition
6. Input Power: 5V DC power supply / computer USB to take power
7. Work axis stepper:Received the highest 5-axis independent driving
8. Drive:Pulse + direction + enable signal

B. Power supply
250W 24V 10A switching power supply

C. Stepper Motor
57BYGH56-401A Stepper Motor(1.2N.m 2.8Aï‰
Wiring: Black: A+
Green: A-
Red: B+
Blue: B-
Shaft Axial Play: 0.08Max.(450 9-load)
Shaft Radial Play: 0.06Max.(450g-load)
Step Angle Accuracy: +-5%(full step, no load)
Resistance Accuracy: +-10%- Inductance Accuracy: +-20%
Temperature Rise: 80 Degrees Celsius CMax.(ratod current,2 phase on)- Ambient Temperature: -10°C-+50°C
Insulation Class: B
Dielectric Strength: 500V AC for one minute

D. Stepper Motor Driver
Input voltage DC 12 ~ 36V input
The input current of 1 to 4 amps, select the drive a stepper motor.
Output current of 0.5A ~ 3.5A
Temperature Operating Temperature -10 to 45 „ƒ; Storage temperature -40 „ƒ to 70 „ƒ
Humidity not condensing, not drops
Gas prohibit combustible gas and conductive dust

What`s in box?
1 x USB CNC breakout board
4 x stepper motor driver
4 x Stepper Motor
1 x power supply
