C & A Scientific Premiere SMJ-04 Binocular Stereo Microscope, 10x Eyepieces, 40x Magnification, 4x Objective, Upper Halogen Illumination
The C & A Scientific Premiere SMJ-04 binocular stereo microscope has 10x widefield eyepieces, 4x objective with 40x total optical magnification, upper 10W halogen lighting, a fixed stage with dual focusing knobs, and a reversible (black/white) 60mm stage plate. The binocular viewing head has a pair of eyepieces, fixed inclination to reduce eye and neck strain, and eye shields to block ambient light. The objective provides low magnification and a longer focal length for inspecting large-scale specimens, or specimens that require hands-on manipulation or repair, including rocks, minerals, watches, or circuit boards. Dioptric adjustment accommodates individual eye-strength differences. The microscope has upper (episcopic) illumination that reflects light off the specimen for enhanced visibility of opaque specimens. The halogen light source provides bright light in a concentrated path. The reversible black and white stage plate is used with top-mounted (episcopic) lighting to provide contrast with light- and dark-colored specimens. The fixed stage has stage clips to secure the slide or specimen in place while viewing. Dual knobs provide precise focus. A stereo microscope, sometimes called an inspection or dissection microscope, has a longer working distance that enables users to manipulate the object being inspected, and is used in semiconductor and electronics industries or by mineralogists, dentists, and students when the user needs to handle or perform work under magnification, including circuit boards, rocks and gems, and dental appliances.
The microscope stand is constructed of metal for durability. The microscope is approximately 12 x 4-1/2 x 7 inches (H x W x D, where H is height, the vertical distance from the lowest to highest point; W is width, the horizontal distance from left to right; and D is depth, the horizontal distance from front to back). It comes with a vinyl dust cover and a spare bulb.
| Microscope Head and Optics Specifications | |
|---|---|
| Head | Binocular |
| Magnification | 40x |
| Head inclination | 45 degrees |
| Eyepieces | Widefield 10x |
| Objective | 4x, 5mm field of view |
| Microscope Illumination and Stage Specifications | |
|---|---|
| Focus type | Dual knobs |
| Working distance | 57mm |
| Light source | Halogen with on/off switch, 10W |
| Illumination type | Upper |
| Stage type | Fixed, reversible (black/white) 60mm stage plate, two stage clips |
| Microscope dimensions | 12 x 4-1/2 x 7 inches (H x W x D) |
| Weight | 5-1/4lb. |
| Standards | CE marking |
Microscopes are instruments used to enhance the resolution of an object or image. Types include compound, stereo, or digital. Compound microscopes use a compound optical system with an objective lens and an eyepiece. Stereo microscopes show object depth in a three-dimensional image. Digital microscopes are used to display an image on a monitor, rather than looking through a lens. Microscopes can have monocular (one), binocular (two), or trinocular (three) eyepieces, with varying magnification abilities. Magnification ability refers to the size of an image. Resolution, also known as resolvant power, refers to the clarity of the image. The interaction between field of view (FOV), numerical aperture (NA), and working distance (WD) determines resolution. Microscopes can control magnification through a fixed focus, or through a range of adjustments. They can also utilize LED, fluorescent, and mirror light sources to help control viewing capabilities. Microscopes are widely used in education, lab research, biology, metallurgy, engineering, chemistry, manufacturing, and in the medical, forensic science, and veterinary industries.
C & A Scientific manufactures and distributes medical and educational products. The company, founded in 1988, is headquartered in Manassas, VA.
