Bplus SSDMR : Dual mini SATA to SATA RAID Adapter (SSDMR)

Introduction:
SSDMR adapter enables two mini-SATA SSD as a 2.5h HDD by RAID function in the laptop PC or desktop PC.
Once installed, the mSATA SSD behaves like the 2.5hHDD in some RAID mode with faster or more reliable RAID functions, low power consumption, fast access time and completely shock resistant.

Function
Allows user to use standard SATA-IO mSATA SSD to SATA hard drive in the Desktop or Laptop
RAID mode : JBOD (Port Multiplier), RAID0 (Striping/Fast), RAID1(Mirror/Safe), Span (Big)
Support Hi-Speed SATA3 / 6Gbps mass storage interface.
Transparent to the operating system and does not require any software drivers
Dimension: 2.5h HDD size (DxWxH : 70 x 100 x 8 mm)

System Requirement
System supporting SATA 7pin data port and SATA 15pin power.

Notice :
SSDMR can not be used with USB-SATA adapter.

SSDMR Package Content
SSDMR (Dual mini-SATAto SATARAID Adapter) x1
Flat-Head Screw x4
