Bonlux LED Dimmer with Romote 110v 220v Knob Triac LED Dimmer Switch for E27 Gu10 Dimmable Bulb/spotlight/ Downlights


Infrared 14-Key Triac Dimmer 110V 220V Knob Triac LED Dimmer Switch for E27 GU10 Dimmable Bulb/Spotlight/ Downlights

Specifications:

Working temperature: -20-60 ℃
Input voltage: AC 110-240V (50Hz/60Hz)
Output:1 circuit
Dimensions: L87.5 × W87.5 × H53mm
Controller size:L86 × W33 × H7mm
Packaging sizes: L160χW95χH51mm
the static power consumption: <1W
output power: 300W

IR Control Key Function

1. to connect the load line, then the power line; power to ensure that no short before the connection line between the phenomenon
2. during the operation, the remote control to the infrared receiving head, make sure there are no obstacles between the remote controller and the receiver.
3. remote control panel red buttons: turn on or shutdown
4. remote control panel 10%--90% buttons: Brightness selection.
5. FLASH: dynamic flashing button, adjustable speed.
6. + - function keys: static and dynamic tune tune brightness, speed.
7. potentiometer adjustment mode: Clockwise rotation knob brightness will increase; counterclockwise rotation knob brightness will decrease.

Package include:

1x LED Dimmer
1x 14 Key IR Remote Controller
1x User Manual
