BD-10AV Generator with Chinese Plug, 230V

Model Introduction: Generates a spark at a high voltage and frequency, used to detect pinholes and vacuum leaks, and in the classroom to light spectrum tubes and florescent bulbs. It is lightweight, self-contained hand held. For light duty, intermittent use. Not to be operated for more than 10 minutes at a time, with a cool down period to follow. Key Features and Operating Characteristics: It is made of durable plastic, with an 8 ft. cord. It has a control knob on the high voltage handle to adjust the output voltage. The electrode used provides safety by using a spacer to isolate power line voltage in the event of a internal short-circuit with the device. Output voltage is adjustable from 20,000 to 50,000 Output frequency is 500 kHz. Output current is approximately 0.1 mA maximum. Separate models operate from either 115 or 230 VAC, 50/60 Hz. Overall dimensions: 11x2.5 without electrode.
