Atik 383L+ Color CCD Camera w/ Kodak KAF-8300 Sensor ATK0068


Atik 383L+ Color CCD Camera w/ Kodak KAF-8300 Sensor ATK0068

Redefining mid-range astro imaging, the new Atik 383L+ is an 8 Megapixel camera featuring the Kodak KAF-8300 CCD. This design by Atik makes it easier for enthusiasts to access multi-megapixel, cooled cameras more easily with its irresistible price. The 383L+ is a fantastic CCD with a huge number of good-sized pixels.

ATIK provides cameras with very high image quality but at affordable prices. The ATIK 383L+ is no exception, offering the same high quality at reasonable cost. The Platform 3 by ATIK is featured with the 383L+ and it supports the Kodak KAF-8300. The advantages of this design provide very low read-noise circuits and reliability.

The camera can be used with either the EFW-U or our new EFW2 and Off Axis Guider (coming soon). Standard 1.25 filters can be used for focal ratios of f/5 and above without vignetting. Faster focal ratios will need flat-field correction or 36mm filters.

Atik 383L+ CCD Camera Color Features
Ultra low read-noise for great sensitivity
8.3 Million 5.4m square pixels for high-resolution imaging
Lightweight - no flexure of the telescope focuser tube
Highly efficient setpoint cooling to 40 degrees max below ambient
High-Quality mechanical shutter
Externally accessible desiccant plugs
Great software for image acquisition and pre-processing
Memory Buffer to reduce readout artifacts

For data acquisition and camera control, the acclaimed Capture software is included as well as plug-ins to allow use with Maxim DL, Astroart, and CCDSoft.

System requirements: Pentium II PC with 64MB RAM, Windows 98/XP/Vista, CD-ROM drive and USB 2.0 port.

Designed for a wide range of image sensing applications, the Kodak KAF-8300 Image Sensor is a 22.5mm diagonal (Four Thirds Format) high performance monochrome or color full frame CCD (charge-coupled device) image sensor. Digital imaging ca

  • BindingElectronics
  • BrandAtik Cameras
  • LabelAtik Cameras
  • ManufacturerAtik Cameras
  • MPNATK0068
  • PackageQuantity1
  • PartNumberATK0068
  • ProductGroupPhotography
  • ProductTypeNameTELESCOPE
  • PublisherAtik Cameras
  • StudioAtik Cameras
  • TitleAtik 383L+ Color CCD Camera w/ Kodak KAF-8300 Sensor ATK0068
