American Carbide Tool Carbide-Tipped Pointed Nose Lathe Tool Bit, D Style, Neutral Hand, C5 Grade, 0.25" Square Shank, D 4 Size

The American Carbide Tool carbide-tipped pointed nose lathe tool bit has a D style with a neutral-hand cutting direction and a C5 grade for light turning, undercutting, chamfering, and boring applications on soft steel and steel alloys. The D style, also called pointed nose, tool shape has an 80-degree included angle and provides a neutral-hand cutting direction for right-to-left or left-to-right feed. The tool tip is made of C5 grade uncoated carbide for good resistance to shock and wear and is brazed onto a steel shank for strength. The square shank fits square toolholders.

Brazed tools, also called carbide-tipped lathe tool bits and single-point brazed carbide-tipped tools, are used for metal shaping on lathes. These single-point tools have a cutting edge at one end that is a carbide tip brazed to a steel shaft. They come in multiple geometry styles for different cutting applications and are identified by a lettering standard that conforms to American National Standards Institute (ANSI) B212.1 specifications. Brazed tools are available in three hand options: right, left, and neutral. A right-hand tool has its principal cutting edge on the right side of the tool to feed into the workpiece from right to left, a left-hand tool feeds into the workpiece from left to right, and a neutral-hand tool will cut either left to right or right to left. The side cutting and end cutting edge angles, in combination with the angle at which the tool is positioned in relation to the workpiece (also called the lead angle), help determine the tool's cutting shape and action.

American Carbide Tool manufactures standard single-point brazed carbide-tipped tools, and precision ground cutting tools and inserts. The company, founded in 1953, is headquartered in Canton, OH.

  • TitleAmerican Carbide Tool Carbide-Tipped Pointed Nose Lathe Tool Bit, D Style, Neutral Hand, C5 Grade, 0.25" Square Shank, D 4 Size
  • BrandAmerican Carbide Tool
  • ManufacturerAmerican Carbide Tool
  • BindingMisc.
  • ProductGroupBISS
  • ItemPartNumberD 4 C5
  • ModelD-4 C5
  • ColorFJ2308190743
  • SizeD 4
  • UnitCount1
  • UPCs726761530197
  • EANs0726761530197
