Adafruit Motor Shield for Arduino Kit

Easy to use and full featured motor driver shield for Arduino. Made by Adafruit. Comes in kit form, requires soldering. 2 connections for 5V 'hobby' servos connected to the Arduino's high-resolution dedicated timer - no jitter! 4 H-Bridges: L293D chipset provides 0.6A per bridge (1.2A peak) with thermal shutdown protection, internal kickback protection diodes. Can run motors on 4.5VDC to 36VDC. Up to 4 bi-directional DC motors with individual 8-bit speed selection (so, about 0.5% resolution) Up to 2 stepper motors (unipolar or bipolar) with single coil, double coil or interleaved stepping. Pull down resistors keep motors disabled during power-up Big terminal block connectors to easily hook up wires (18-26AWG) and power Arduino reset button brought up top 2-pin terminal block and jumper to connect external power, for separate logic/motor supplies Tested compatible with Arduino Mega 1280 & 2560, Diecimila, Duemilanove, and UNO Download the easy-to-use Arduino software library, check out the examples and you're ready to go!
