Adafruit 1330 Peltier Thermoelectric Cooler Module, 12 Volt, 5 Amp
Type
Price
Date
Current Price
$16.95
2023-12-08
Highest Price
$16.95
2023-12-08
Lowest Price
$16.95
2023-12-08

Adafruit 1330 Peltier Thermoelectric Cooler Module, 12 Volt, 5 Amp

Keep the heat down with a peltier module. These unique electronic coolers can generate a temperature differential when powered. Put simply, apply 12V to the red (positive) and black (negative) wires and one side will get cold while the other side gets hot. For best results, you'll need to wick away that heat (otherwise the cold side will slowly get warmer). a fan and/or heatsink is ideal. This is a 12V module, and is rated for up to 72 Watts max (up to 14V/6a) but when used with a regulated 12V output, they don't draw more than 5 Amps, so we suggest our 12V/5a power adapter for use. (You will need to cut the connector and expose the wires or use a power jack to screw terminal adapter.). Max current: 6a at 12V. Suggested voltage range: 12V to 15.5V. Maximum temperature differential (tmax at QC = 0): 66°c. Maximum cooling power (QC max.) at 15.3V: 97W. 127 peltier elements. DC resistance: 2.5 ohms. Silicone seal.

  • TitleAdafruit 1330 Peltier Thermoelectric Cooler Module, 12 Volt, 5 Amp
  • BrandAdafruit
  • ManufacturerAdafruit Industries
  • BindingMisc.
  • ProductGroupBISS
  • ItemPartNumber1330
  • Model1330
  • ReleaseDate2017-03-12T00:00:01Z
  • UnitCount1
  • UPCs701851956583
  • EANs0701851956583
