CONNECTORS
24 auto-negotiating 10BASE-T/100BASE-TX ports configured as auto MDI/MDIX MEDIA INTERFACES
10/100/BASE-TX RJ-45 or 10/100/1000BASE-T RJ-45, depending on modelPERFORMANCE
Wirespeed performance across all ports Store-and-forward switchingLAYER 2 SWITCHING
MAC addresses: 4K LED INDICATORS
Link status/speed, duplex status, powerPOWER SUPPLY
Input voltage: 100-240 VAC, 50/60 Hz Current rating: 1A, max. Power inlet: IEC 320 Power consumption, max: 16W Power dissipation, max: 55 BTU/hr DIMENSIONS
Height: 4.4 cm (1.7 in or 1 RU) Width: 44.0 cm (17.3 in) Depth: 17.3 cm (6.8 in) Weight: 1.6 kg (3.6 lb) ENVIRONMENTAL REQUIREMENTS
Operating temperature: 0? to 40?C (32? to 104?F) Operating humidity: 10 to 95% (non-condensing) Standard: EN 60068 (IEC 68)IEEE STANDARDS SUPPORTED
IEEE 802.1d MAC Bridges IEEE 802.3 Ethernet IEEE 802.3u Fast Ethernet IEEE 802.3x Flow Control ISO 8802-3WARRANTY AND OTHER SERVICES
Three Year Limited HardwareWarranty,including fans and power supply Limited SoftwareWarranty for 90 days Advance Hardware Replacement with Next Business Day shipment in most regions 90 days of telephone technical support Refer to 3com/warranty for details.
